SUTOP® PU-1BPolyurethane-Based UV Resistant Single Component Elastic Water Insulation Material

APPLICATION FIELD

  • Used safely on terraces, ceilings, balconies and gutters,
  • On foundation and curtain walls, window boxes,
  • On the exterior façades of the buildings,
  • In wet areas under tiles,
  • For the UV strength of polyurethane foam applications,
  • And against water and corrosion on applications such as concrete, rock, eternit, wood and metal sheets, etc.

REQUIREMENTS

  • It has a single component and is ready to use.
  • It may be applied easily (With a roll or an airless sprayer).
  • It may be applied without any joints.
  • Resistant against collected water.
  • Offers high resistance against UV and frost.
  • It is cured by reacting with the humidity in the air.
  • Maintains its characteristics between -30 ºC and +90 ºC.
  • Offers water vapour permeability.
  • Features perfect adherence properties.

TECHNICAL VALUES

Colour

White, Grey

Density

1,40 g/cm3

Solid Content

~ % 90

Service Temperature

-30 ºC / +90 ºC

Floor Temperature

+5 ºC / +30 ºC

Walking on The Surface

16-24 hours at +23 ºC

Shore hardness

65 (7 days)

Tensile Strength DIN 53 504

> 5 N/mm2 (7 days)

Breaking Strain DIN 53 504

% 800 (7 days)

Chemical resistance

Acidic and basic solutions

Water Vapour Permeability

Sd: 1,6 m

Crack Bridging

2 mm

NOTE: Technical data are given for environments with a temperature of +23 °C and a relative humidity of 50%.

APPLICATION

SURFACE PREPARATION

  • Application surface shall be solid, free of any type of oil, grease, corrosion, paraffin, paint, bitumen residues and any loose parts shall be moved away.
  • The surfaces to be applied with primer shall be free from dust and shall not contain errors such as dents, breaks and cracks, etc.
  • Such uneven surfaces and corner edges shall be repaired with DOLTEK® repair mortars with a minimum radius of 4 cm before the application.
  • If SUTOP® PU-1B shall be applied on absorbent surfaces such as concrete, precast concrete etc., it shall be primed with SUTOP® PRIMEL PU; and if shall be applied on bright non-absorbent surfaces such as ceramic, granite, marble, metal etc., it shall be primed with SUTOP® PRIMEL PU (SILAN).
  • Wait at least for 3-4 hours to ensure that the primer has dried.
  • Primer shall be applied to the surface by a roll, brush or sprayer.

PREPARATION of the MORTAR

  • SUTOP® PU-1B” that has been kept in room temperature for 24 hours is mixed with a mixer with a suitable mixer bit at 300-400 rpm until the mixture becomes homogeneous.
  • The mixture obtained shall be applied to the primed surfaces as one coat or two coats using a thin comb, trowel, roll brush with short bristles or with a suitable sprayer.
  • The layer shall protected against water rain, external factors and mechanical forces until it is dried.
  • While the waiting period between application of coats varies as per the ambient conditions, the period to start the second coat is usually 12 hours.
  • You shall consider that the waiting period may be reduced in hot weather and that it may be longer in cold weather.

CONSUMPTION

Standard Use:
SUTOP® PRİMEL PU   0,20 kg/m²  /  SUTOP® PU-1B   0,75 – 1,00 kg/m² (for a single coat)
Reinforced Use:
SUTOP® PRİMEL PU   0,20 kg/m²  /  SUTOP® PU-1B   0,85 – 1,25 kg/m² (for a single coat)
Note: The values provided in our table are the average consumption values. Additional consumption shall be determined by the user according to different surface properties.


PACKAGING

25 kg circular lids canister

(istenildiği takdirde paletli olarak sevk edilir)

STORING

1 Year Shelf Life*

* If stored in its original package without opening the package under dry, frost free conditions

CERTIFICATE OF CONFORMITY

RECOMMENDATION

  • Contains solvents, combustible.
  • Water vapour pressure from the negative side shall not be observed on the application surfaces.
  • After application, the surface shall be protected against water, rain, dew, snow, hail, etc. until it is dry.
  • It shall not be applied in enclosed areas due to long-lasting solvent odour, and the surface temperature shall be +5 ºC.
  • After the application, tools shall be cleaned with soapy water and thinner.
  • The package shall be kept at +15 ºC for at least 24 hours during application.
  • It should be considered that full mechanical and chemical strength shall be achieved in 7 days.
  • Storage conditions shall be considered while it is transported.
  • Work clothing, protective gloves and goggles conforming with the Occupational Health and Safety Rules shall be used during the application.
  • Do not inhale it directly.
  • Do not approach with open flames and do not smoke during application.
  • Avoid contact with eye and skin. In case of contact, wash with plenty of water and soap.
  • Consult a physician immediately in case of swallowing.
  • Do not use empty packages to store food and do not throw them in fire.
  • Food and drinks shall not be allowed in application areas.
  • Shall be stored away from the children.
  • Do not go beyond the application field and the rules.
  • For detailed information, please request the security data sheet.
  • Contact us for your technical questions and for your questions about all other application conditions.
