  WATERPROOFING SOLUTIONS CEMENT BASED SUTOP ÇiFT TAM ELASTiK®

PRODUCTS

SUTOP ÇiFT TAM ELASTiK®Cement and Acryllic-Based Double Component Full Elastic Water Insulation Material

APPLICATION FIELD

  • Used in wet areas such as bathrooms, WCs, kitchens, balconies, etc. and for insulation of water tanks, pools and terraces.
  • Applied on surfaces such as concrete, plaster and screed.

REQUIREMENTS

  • Has high elasticity.
  • It may be easily and rapidly applied.
  • Resistant against contraction cracks.
  • May be applied on horizontal and vertical surfaces.
  • Has a superior adherence.
  • Suitable for contact with drinking water.
  • Applied against positive water pressure.

TECHNICAL VALUES

Water Vapour Permeability

Class I

Shear Tensile Adhesive Strength

With no traffic load / Flexible

Class of Reaction To Fire

E

Adhesive Strength, N/mm²

≥1

Capillary Water Absorption and Water Permeability (kg/m²h0.5)

Max 0,1

Crack Bridging Ability, mm

>  0,75



MSDS - Safety Data Sheet Ürünün Güvenlik Bilgi Formunu görüntülemek ve indirmek için tıklayınız. TDS - Technical Information Form Ürününün Teknik Bilgi Formunu görüntülemek ve indirmek için tıklayınız.

APPLICATION

SURFACE PREPARATION

  • The surface of application shall be free solid, clean, free of dust and level.
  • The surface shall always be free of materials such as form oil, paint, dust etc., and shall be fully cured.
  • Parts on the surface (iron, wood, etc.) shall be removed and these hole shall be filled with appropriate Entegre Repair Mortars.
  • You may advance to application after dampening the surface.

PREPARATION of the MORTAR

  • A proper amount of fluid component shall be put inside the mixing vessel (10 kg of fluid/20 kg of powder).
  • Whole bag is poured to the vessel, and stirred with hand mixer until the lumps are removed.
  • After resting for 5 minutes, the mortar shall be stirred again. ENTEGRE CHAMFERING TAPE shall be applied to the connection points of the application surfaces using EPODOL®.
  • If you do not prefer chamfering tapes, bring the connection points to an oval form and reinforce them with nets.
  • Fluid mortar shall be applied with a brush or a roll. Second coat shall be perpendicular to the first coat and shall be applied at least for 6 hours later.
  • Wait 3 days for application of final coat (ceramic, screed and cement-based plaster), and take care to prevent mechanical damage to the insulation material during coating.
  • If the application area is a water tank, wait at least 28 days for the curing of the product.


CONSUMPTION

1.5-2.0 kg/m² single coat

(Application at proper surface and ambient conditions is taken as a reference.
It may differ as per surface specifications and application conditions.)

PACKAGING

A Component: 20 kg polyethylene-reinforced kraft paper bags,

B Component: 10 kg plastic drums

(delivered in pallets or as sling-bags upon request.)

STORING

1 Year Shelf Life*

* If stored in its original package without opening the package under dry, frost free conditions



(1 week after opening the package.)

Likit bileşen 0 °C’nin altındaki sıcaklıklarda donmaktadır.)

CERTIFICATE OF CONFORMITY

TS EN 1504-2 / April 2008
It is suitable for contact with drinking water as per BS6920 standard.
(Ege University - Department of Chemistry
Report No: 13052003  Report Date: 20.05.13)
Ministry of Public Works Pos. No: 04,477/1

RECOMMENDATION

  • No other materials than these two components (lime, cement, gypsum, etc.) shall be added.
  • We recommend you to stir the product continuously during application.
  • Mortar shall not be used again by mixing with water, fluid component or dry mortar if its application time has expired.
  • We recommend that the application shall be performed between +5°C and +35°C.
  • SUTOP CIFT TAM ELASTIK® shall be protected against effects such as sunlight, wind, rain and frost, etc. within the first 24 hours after application.
  • Reaches its final strength within 14 days.
  • It shall not be applied on frozen surfaces.
  • Do not apply under direct sunlight.
  • Do not go beyond the application field and the rules.
  • Do not inhale it directly. Wash your eyes with plenty of water in case of contact with eyes, seek medical attention if required.
  • For detailed information, please request the security data sheet.
  • Contact us for your technical questions and for your questions about all other application conditions.
