ENTEGRE DiLATASYON BANDIThermoplastic Elastomer Based Water Insulation Tape With High Elasticity

APPLICATION FIELD

Used in dilatations of whole buildings, in vertical or horizontal applications, on the underground parts of foundations and curtains, in permanently wet areas such as drinking water facilities, waste water treatment plants, pools and water tanks, on tunnels and vents, and for water insulation of raft-curtain, curtain-curtain cold joints, expansion joints and cracks.

REQUIREMENTS

  • Has high elasticity (600%). Allows easy application with epoxy adhesive. Has high adhesion strength.
  • Resistant against plant roots.
  • Resistant against UV rays, fuel oil and oil.
  • Provides high performance at wide temperature range (-40, +90 ºC).
  • Provides the feature of combining to each other when the temperature increases.
  • We offer our products with the following sizes and thickness values with the option for selecting between porous and non-porous.

TECHNICAL VALUES

Chemical Properties of the Material

Thermoplastic Elastomer (TPE)

Colour

Grey

Shore Hardness

80

Service Temperature

- 40 ºC, +90 ºC

Temperature of Thermal Source

270 ºC

Breaking Strain

600 %

Tearing Strength

˃ 600 N/cm

Strength Against Water Pressure

˃ 8 bar

Tensile Strength

˃ 6 MPa

UV Strength

˃ 7500 h

Bitumen Strength

  Good

Sulphuric Acid Strength

  Good

Alcohol Strength

  Good

Detergent Strength

  Good



PACKAGING

25 mt’lik rulo bobin



Delikli ve Deliksiz seçenekleriyle aşağıdaki ebat ve kalınlıkta ürünümüz bulunmaktadır

Width

Thickness

15 cm

1 mm & 1,5 mm

20 cm

1 mm & 1,5 mm

25 cm

1 mm & 1,5 mm

30 cm

1 mm & 1,5 mm

40 cm

1 mm & 1,5 mm



CERTIFICATE OF CONFORMITY
